Book of Dreams
This compilation of our work is available as a 125-page book including yacht profiles, interior layouts, technical articles and introductions to each section by Pat Bray.



$35
Stock Plan Designs
DINGHIES
Water Rat 7'-8' sailing, rowing (w) $25
Sea Otter 7'-9" sailing, rowing, motoring (w/e) $25
Exuberance 14'-6" sailing, rowing, motoring (w) $35
Dorado 15'-0" high performance sailing (w/e) $50
Flying Fish 18'-0" sailing, rowing, motoring kayak (w/e) $50
SAILBOATS
Mud Puppy 22'-0" pocket cruiser (w/e) $200
Bray 7.5 M 24'-6" cruiser/racer (w/e) $350
Sarah 30'-0" live aboard cruiser (w/e) $1000
Susan 35'-6" world cruiser (s) $1500
Lady Jane 40'-0" world cruiser (s, a) $2000
Silver Seas 45'-6" Ocean cruiser (a) $2500
MOTORSAILERS
Freestyle 27 27'-0" trailerable RV (f) $1000
Gina 36'-9" cruiser (w/e) $1600
POWERBOATS
Sprint 22 22'-4" sport boat (w/e) $200
Sprint 25 25'-0" bow rider (a) $250
Sprint 27 27'" sport boat (a) custom plan
11.6 M 38'-0" sportfisherman (f, a) $1800
Elizabeth 50'-6" catamaran motoryacht (w/e) custom plan
Hi Dad 57'-0" world cruiser (f, a) custom plan

a = aluminium
w/e = wood/epoxy or wood/epoxy glass
w = wood
s = steel
f = fiberglass or foam cored fiberglass

  • Plans comprise of multiple drawing sheets (except dinghies) and a complete book of specifications.
  • Vessels are specifically designed for the materials listed and are not available in other materials.
  • Design modifications are possible. Custom designs are our business.

To Order Plans and/or
our Book of Dreams
Please contact us at (604) 531-8569 or pat@brayyachtdesign.bc.ca.
